DC Power Supplies
| Series | Type | Channels | Total Power | Output Voltage | Output Current | Resolution | Setting Accuracy | Connectivity |
|---|---|---|---|---|---|---|---|---|
UDP4303S
|
Linear | 4 | 297W | 0 - 32V | 0 - 3A | 1mV,1μA | <0.03%+8mV, <0.15%+5mA | RS-232,USB Host, USB Device,LAN, Digital IO, Sense |
UDP6900
|
Switching | 1 | 600W | 0 - 150V | 0 - 25A | 0.1mV,0.1mA | <0.03%+5mV, <0.1%+5mA | RS-232, USB Device, LAN, RS485 |
UDP3000S
|
Linear | 4 | 328W | 0 - 30V | 0 - 5A | 1mV,1mA | <0.03%+10mV, <0.2%+5mA | RS-232, USB Device, LAN, USB Host, Digital IO |
UDP6700
|
Switching | 1 | 360W | 0 - 80V | 0 - 30A | 10mV,1mA | <0.05%+10mV, <0.2%+2mA | RS-232 |
UDP3000
|
Linear | 3 | 315W | 30V | 5A | 10mV,1mA | <0.01%+3mV, <0.2%+3mA | RS-232, USB Device |
UDP3300-II
|
Linear | 3 | 335W | 32V | 5A | 10mV,1mA | <0.01%+3mV, <0.1%+3mA | / |
UDP3300TFL-II
|
Linear | 1 | 150W | 30V | 5A | 10mV,1mA | <0.01%+3mV, <0.1%+5mA | / |
