UTS5026A Signal Analyzer

  • FREQUENCY RANGE: 9kHz~26.5GHz
  • RBW: 1Hz~3MHz (10% step), 4, 5, 6, 8MHz
  • PHASE NOISE : -107dBc/Hz @10kHz
  • DANL: -163dBm
  • TRACE SOURCE: 25 MHz/ 40 MHz(option)
  • DISPLAY: 15.6 inch 1920 x 1080 HD thin film transistor LCD display screen

5 Years Warranty Included*

Click here for details

Excl. VAT         €29.999,00
€35.698,81 Incl. 19% VAT

UTS5026A Signal Analyzer

UTS5026A Signal Analyzer

Specification

  • Wide Frequency Measurement Range: Covers 9 kHz to 26.5 GHz, enabling precise analysis across a broad spectrum.
  • Superior Display Average Noise Level (DANL): Achieves a noise floor as low as -163 dBm (typical), ensuring excellent sensitivity for weak signal detection.
  • Outstanding Phase Noise Performance: Delivers phase noise better than -107 dBc/Hz (offset 10 kHz, typical) for accurate signal analysis.
  • High-Resolution Scanning: Supports up to 100,001 scanning points, improving frequency resolution and signal capture accuracy.
  • Ultra-Fine Resolution Bandwidth (RBW): Offers a minimum RBW of 1 Hz for precise spectral analysis.
  • Advanced One-Key Measurement (Optional): Simplifies complex measurement tasks with quick, automated analysis.
  • EMI Pre-Compliance Testing (Optional): Includes optional components and near-field probes for early EMI defect detection and resolution.
  • Analog Demodulation Analysis (Optional): Supports AM, FM, and PM signal demodulation for versatile signal testing.
  • Large 15.6-inch Multi-Touch HD Display: Features a 1920 x 1080 capacitive touchscreen for an intuitive and efficient user experience.
  • Enhanced User Interaction: Multi-gesture support (dragging, zoom-in, zoom-out) allows easy manipulation of traces and settings.
  • Removable Dust Mesh: Enables easy maintenance by allowing users to clean the air inlet and prevent dust-related damage.
  • Rich Peripheral Connectivity: Supports keyboard, mouse, storage devices, upper computer connections, remote control, web control, multi-device synchronization, and a 3.5mm headphone jack for enhanced usability.
  • Superior Selectivity: Ensures high-resolution signal differentiation, making it easier to analyze closely spaced signals of different amplitudes.

Features

  • Powerful hardware system
  • Excellent selectivity

    Selectivity factor up to 4.1:1. Better ability to distinguish adjacent signals

  • 100,001 scan points

    Display more detailed, higher frequency resolution

  • Excellent sensitivity

    DANL is as low as -163dBm, with excellent sensitivity and can effectively test weak signals

  • Excellent phase noise

    Phase noise as low as -107 dBc/Hz (1 GHz, 10 kHz offset)

  • HD large screen display

    15.6inch (1920x1080) Multi-touch

  • Removable dust mesh

    Patent No：CN202220722753.3
    Clean the product regularly without removing the entire case. Just remove and wash the dust cover and dust net

Related Document

User Manual
Datasheet
Quick Start Guide
Programming Manual
Software and Firmware

Option For UTS5026A Signal Analyzer

  • UTS5000A-AMA
    Excl. VAT €725,00

    Incl. 19% VAT €862,75



    Analog Demodulation Measurement UTS5000A Series
    Download
    Delivery Content

  • UTS5000A-AMK
    Excl. VAT €1.250,00

    Incl. 19% VAT €1.487,50



    Advanced Measurement Kit for UTS5000A Series
    Download
    Delivery Content

  • UTS5000A-EMI
    Excl. VAT €1.068,00

    Incl. 19% VAT €1.270,92



    EMI Analysis for UTS5000A Series
    Download
    Delivery Content

  • UTS5000A-P26
    Excl. VAT €2.315,00

    Incl. 19% VAT €2.754,85



    UTS5026A Preamplifier, 26.5 GHz
    Download
    Delivery Content

  • UTS5000A-VSA



    Vector Signal Analysis option
    Download
    Delivery Content
View all

Accessories for UTS5026A Signal Analyzer

  • BAG-B3
    Excl. VAT €65,00

    Incl. 19% VAT €77,35



    Soft carrying bag for UTS1000B and UTS3000B Series Spectrum Analyzers

    Download
    Delivery Content

  • UTS-EMI01
    Excl. VAT €429,00

    Incl. 19% VAT €510,51



    Frequency range: 30MHz ~ 3GHz； include 3 Pcs magnetic field near-field probes and 1 Pcs electric field near field probe; 1 Pcs N-SMA cable, 1 Pcs N-BNC

    Download
    Delivery Content

  • UT-CKO1 Test Kit
    Excl. VAT €249,00

    Incl. 19% VAT €296,31



    Spectrum Utility Kit: include NSMAJ-NJ-0.7M DC-6G Cable x1, NJ-NJ-0.7M DC-6G Cable x1, SMA-N-KJ-T DC-6GHz Adapter x2,N-BNC-JK DC-4GHz Adapter x2, 2400MHz-2500MHz Antenna x2, 824-960MHz/1710-1990MHz x2

    Download
    Delivery Content

  • UT-C01-6GHz
    Excl. VAT €29,00

    Incl. 19% VAT €34,51



    N-SMA-JK adaptor，DC-6GHz VSWR≤1.15:1@6GHz IL≤0.2dB@6GHz
    Download
    Delivery Content

  • UT-C02-4GHz
    Excl. VAT €29,00

    Incl. 19% VAT €34,51



    N-BNC-JK adaptor，DC-4GHz VSWR≤1.15:1@4GHz IL≤0.2dB@4GHz
    Download
    Delivery Content

  • UT-W01-6GHz
    Excl. VAT €55,00

    Incl. 19% VAT €65,45



    N-N-JJ RF cable, 0.7m, DC-6GHz VSWR≤1.25:1@6GHz IL≤1.8dB@6GHz
    Download
    Delivery Content

  • UTS-T02
    Excl. VAT €15,00

    Incl. 19% VAT €17,85



    Receiving antenna，working frequency 824MHz-960MHz，Gain<2dBi

    Download
    Delivery Content

  • UTS-T01
    Excl. VAT €15,00

    Incl. 19% VAT €17,85



    Receiving antenna，working frequency 2400MHz-2500MHz，Gain<2dBi
    Download
    Delivery Content

  • UT-C03-18GHz
    Excl. VAT €79,00

    Incl. 19% VAT €94,01



    SMA-N-KJG adaptor，DC-18GHz VSWR≤1.15:1@18GHz IL≤0.3dB@18GHz
    Download
    Delivery Content

  • UT-C04-40GHz
    Excl. VAT €79,00

    Incl. 19% VAT €94,01



    2.92-KKG adaptor，DC-40GHz VSWR≤1.20:1@40GHz IL≤0.3dB@40GHz
    Download
    Delivery Content

  • UT-W03-6GHz
    Excl. VAT €339,00

    Incl. 19% VAT €403,41



    2.92J-2.92J RF cable，DC-40GHz VSWR≤1.25:1@40GHz IL≤3.5dB@40GHz
    Download
    Delivery Content

  • UT-W02-6GHz
    Excl. VAT €55,00

    Incl. 19% VAT €65,45



    N-SMA-JJ RF cable, 0.7m, DC-6GHz VSWR≤1.25:1@6GHz IL≤1.8dB@6GHz
    Download
    Delivery Content
View all
