UT8805E Bench multimeter
- Resolution: 5½
- FASTEST TEST RATE: 5k rdgs/s
- frequancy Response: 100kHz
- Excl. VAT
- Excl. VAT €455,00
€541,45
Incl. 19% VAT
Share
UT8805E Bench multimeter
Specification
| Feature | Specification |
|---|---|
| Model Number | UT8805E |
| Fastest Test Rate | 5k rdgs/s |
| Frequency Response | 100kHz |
| Resolution | 5½ |
| Connectivity |
USB Device, USB host, LAN, RS-232
|
| Digits | 5.5 |
| Count | 199,999 |
| Ranging | True |
| TRMS | True |
| Accuracy | 0.015% |
| Warranty | 3 years |
| Shipping Dimensions (L x W x H) | 15 in x 13 in x 13 in |
| Shipping Weight | 4 kg |
| For additional product specifications, please refer to the attached PDF. |
|
Features
Video
Comparison
| Model | UT8802E | UT8803E | UT8804E | UT8805E | UT8806E |
| Readind Resolution | 4½ | 3⅚ | 4⅚ | 5½ | 6½ |
| Fastest Test Ratae | 3 rdgs/s | 5k rdgs/s |
10k rdgs/s |
||
| frequency Response | 1kHz | 100kHz |
300kHz | ||
| Accuracy | 0.1% | 0.3% | 0.025% | 0.015% | 0.0035% |
| Connectivity | USB Device | USB Device, USBHost,LAN,RS-232 | USB(Device & Host), LAN, RS-232C, GPIB (option) | ||
| Price | €119,00 | €159,00 | €249,00 | €455,00 | - |
Related Document
User Manual
UT8805E User's Manual
Datasheet
UT8805E DataSheet-EN
Programming Manual
UT8805E Programming Manual
Software
UT8805E Software
UT8805E Firmware
UT8805E Firmware
