USG5014M-P RF Signal Generator

  • FREQUENCY RANGE: 9 kHz - 22 GHz
  • FREQUENCY RESOLUTION: 0.001 Hz
  • LEVEL RANGE: -135 dBm - +25 dBm
  • PHASE NOISE: ＜-122 dBc/Hz(1GHz@20kHz)
  • MECHANICAL ATTENUATOR: Yes
  • DISPLAY: 5 inch TFT LCD (touch screen)

5 Years Warranty Included*

Click here for details

Excl. VAT         €20.199,00
€24.036,81 Incl. 19% VAT

USG5014M-P RF Signal Generator

USG5014M-P RF Signal Generator

Specification

  • Model: USG5014M-P
  • Frequency Range: 9 kHz - 14 GHz
  • Frequency Resolution: 0.001 Hz
  • Output Power Range: -135 dBm to +25 dBm
  • Low Phase Noise Performance: Achieves phase noise as low as -122 dBc/Hz at 1 GHz with a 20 kHz offset, ensuring high signal purity.
  • Analog Modulation Capabilities: Supports AM, FM, and ΦM modulation types, with options for internal, external, and combined modulation sources.
  • Modulation Modes: Internal, external, and internal + external
  • Highly Stable Clock Source: Yes
  • Built-in Waveform Generator: 50 MHz function/arbitrary waveform generator
  • Pulse Modulation and Generation: Offers pulse modulation with an on-off ratio up to 80 dB and customizable pulse trains.
  • Narrow Pulse Modulation: Minimum pulse width of 20 ns with 10 ns resolution (Optional)
  • Sweep Functionality: Includes frequency and amplitude sweep capabilities, supporting step and list sweeps with customizable sweep lists.
  • Power Meter Kit (Optional): Connects via the front panel USB port to enable power measurement, output control, and line loss calibration.
  • User-Friendly Interface: Equipped with a 5-inch TFT LCD touch screen, providing an intuitive graphical display for easy operation.
  • Multi-Interface Connectivity: Supports LAN, USB, and optional GPIB ports for remote control and automation via SCPI commands.
  • Web Control: Allows remote access via a web browser by entering the instrument’s IP address, supporting both PC and mobile devices.
  • Device Management Software: Compatible with UNI-T’s Device Manager (V2.5.0 and higher), enabling control via LAN, USB-TMC, or GPIB.

Features

  • Flat display interface

    With flat design, the human-machine interface is simple and easy to use. Waveforms can be visualized and switched between time domain and frequency domain waveforms on demand

  • Low phase noise performance

    Phase noise as low as -122 dBc/Hz (1 GHz, 20 kHz offset, Typ.)

  • Analog Modulation
    • AM，FM，ΦM and Pulse modulation
    • Supports pulse trains triggering and user-defined pulse trains
  • Sweep
    • Support frequency and amplitude sweep;
    • Support step sweep, list sweep, user can customize the sweep list
  • Function/ Arbitrary Waveform Generator
    • Max. output frequency 50 MHz
    • Supports standard waves, sweep and modulation
  • Power Meter Kit

    The power meter kit connects to the instrument via the front panel USB port, enabling power measurement, power output control, and line loss calibration.

  • High-precision Pulse Generator

    Features a stable clock source, optional pulse modulation and a narrow pulse generator. It has a minimum pulse width of up to 20 ns and a resolution of 10 ns

Comparison

Model USG5022M-P USG5022M USG5014M-P USG5014M
Frequency Range 9 kHz - 22 GHz 9 kHz - 14 GHz
Frequency Resolution 0.001 Hz
Level Range -135 dBm - +25 dBm
Phase Noise <-122 dBc/Hz (1GHz @ 20kHz)
Mechanical Attenuator YES NO YES NO
Display 5-inch TFT LCD (touch screen)

Related Document

User Manual
Datasheet
Quick Start Guide
Programming Manual
Software and Firmware Download

Accesories For USG5014M-P RF Signal Generator

  • UTS-EMI01
    Excl. VAT €429,00

    Incl. 19% VAT €510,51



    Frequency range: 30MHz ~ 3GHz； include 3 Pcs magnetic field near-field probes and 1 Pcs electric field near field probe; 1 Pcs N-SMA cable, 1 Pcs N-BNC

    Download

  • UT-CKO1 Test Kit
    Excl. VAT €249,00

    Incl. 19% VAT €296,31



    Spectrum Utility Kit: include NSMAJ-NJ-0.7M DC-6G Cable x1, NJ-NJ-0.7M DC-6G Cable x1, SMA-N-KJ-T DC-6GHz Adapter x2,N-BNC-JK DC-4GHz Adapter x2, 2400MHz-2500MHz Antenna x2, 824-960MHz/1710-1990MHz x2
