Specification

  • 1 GHz bandwidth for capturing high-speed, high-frequency signals
  • 4 analog + 16 digital channels (MSO) for comprehensive mixed-signal analysis
  • Real-time sample rate of 5 GSa/s for accurate signal reproduction
  • 500 Mpts memory depth to store more waveform data for deep analysis
  • Waveform capture rate up to 1,500,000 wfms/s in sequential mode for detecting rare and infrequent signal events
  • 12-bit high-resolution ADC with ERES (up to 16-bit) for clearer waveform details and signal integrity
  • Ultra Phosphor 3.0 display technology for vivid waveforms and 5–10x faster data processing
  • Integrated 9-in-1 instrument:
    • Digital Oscilloscope
    • Logic Analyzer
    • Arbitrary Waveform Generator (AWG)
    • Spectrum Analyzer
    • Protocol Analyzer
    • Digital Voltmeter
    • Frequency Counter
    • Bode Plot Analyzer
    • Power Analyzer
  • 56 automatic waveform parameter measurements with histogram and trend chart support
  • Supports advanced serial protocol analysis: I2C, SPI, CAN, and 12+ other protocols
  • Zone trigger and hardware mask test for efficient signal filtering and validation
  • Real-time waveform recording: 400,000 frames non-stop
  • 4 Mpts enhanced FFT with multiple windowing functions for detailed frequency domain analysis
  • Multi-window display layout for parallel waveform inspection and measurement
  • 10.1-inch capacitive touchscreen with 1280 × 800 HD resolution
  • Multi-touch gesture support for intuitive operation and fast control
  • SCPI programmable command support for automated test and system integration
  • Built-in web server for remote control on PC and mobile devices
  • USB 3.0 host and device ports for high-speed data access and control

Features

  • Enhanced resolution of 16-bit
    • Higher precision, lower noise floor
    • In 16-bit high-resolution mode, a 12-bit ADC combined with 4-bit ERES enhances measurement accuracy, revealing fine waveform details. This reduces out-of-band and oscilloscope noise, ensuring precise signal analysis with increased sampling bits.
  • Versatile Testing Equipment

    -Oscilloscopes
    -Logic Analyzer
    -Function/Arbitrary Waveform Generator
    -Spectrum Analyzer
    -Protocol Analyzer
    -Power Analyzer
    -Bode plot Analyzer
    -High Precision Frequency Counter
    -Digital Voltmeter

  • Ultra Phosphor 3.0

    supports 8-channel parallel graph mapping, the processing rate is up to 20 Gbps, the waveform capture rate is up to 800,000 wfms/s, and up to 1,500,000 wfms/s in the sequence mode.

  • 56 Types: Measurement, Statistics, Trend Graphs

    56types of precise parameter automatic measurements covering multiple dimensions such as voltage, frequency, phase, and power. It also integrates advanced parameter statistics and trend graph visualization analysis functions, providing a comprehensive and multi-dimensional display of signal characteristic changes, achieving professional-level deep insights and efficient data interpretation.

  • Protocol decoding and triggering
    • Supports 15 types of mainstream protocols, including
    • Embedded: UART, I2C, SPI, I3C
    • Automobile: CAN, CAN-FD, LIN, FlexRay, SENT, CAN-XL
    • Audio: I2S (Audio-I2S, Audio-LJ, Audio-RJ)
    • Aerospace:MIL STD 1553、ARINC 429
    • Wireless communication:Manchester
    • Sensor: 1-WIRE
  • Spectrum Analyzer
    • Standard enhanced FFT with up to 4 Mpts
      for 4-channel signal analysis
    • Frequency range: 0 to 2.5 GHz
    • Waterfall curve
    • 4 traces and 4 detections
    • Mark type: Auto, manual, and threshold
    • Marker point list

  • Power Analysis 6+

    The 6σ (Six Sigma) standard for electronic signals is a process with a defect rate of no more than 3.4 defects per million opportunities (DPMO). This means there are only 3.4 anomalies per 1,000,000 samples. With its ultra-high hardware capture rate, the hardware-accelerated template testing maintains the full capture rate of Ultra Phosphor 3.0, completing waveform tests that meet specific standards within 1 second (instead of several hours).

  • Full hardware real-time triggering

    13 advanced trigger types + 15 protocol trigger types
    New extreme value triggering technology.
    Precisely locking signal extreme points.

  • FIR filter

    The bandwidth is continuously adjustable, effectively filtering out noise and interference within the 50 Hz to 500 MHz range.

  • Hardware-accelerated mask testing: 6σ standard < 1s

    The 6σ (Six Sigma) standard for electronic signals is a process with a defect rate of no more than 3.4 defects per million opportunities (DPMO). This means there are only 3.4 anomalies per 1,000,000 samples. With its ultra-high hardware capture rate, the hardware-accelerated template testing maintains the full capture rate of Ultra Phosphor 3.0, completing waveform tests that meet specific standards within 1 second (instead of several hours).

  • Timing analysis

    MSO5000HD timing analysis function can analyze parameters like pulse width, amplitude, edge, setup time, and hold time for signals for I²C, SPI, and CAN. Additionally, it supports exporting conformance test reports.

Comparison

Model MSO5104HD MSO5054HD MSO5034HD
Bandwidth 1 GHz 500 MHz 350 MHz
Channels 4 Analog + 16 Digital
Sample Rate 5 GSa/s
Memory Depth 500 Mpts
Capture Rate 1,500,000 wfms/s
Resolution 12-bit (up to 16-bit with ERES)
