MSO7104X Mixed-signal Oscilloscope
- Bandwidth: 1GHz
- Channels: 4 Analog + 16 Digital Channel (optional)
- REAL-TIME SAMPLE RATE: 10GSa/s
- Memory depth: 1Gpts
- Waveform capture rate: 2,000,000 wfms/s
- Waveform Generator: 60MHz Dual Channels (optional)
5 Years Warranty Included*
Click here for details
- Excl. VAT
- Excl. VAT €11.999,00
Couldn't load pickup availability
Share
MSO7104X Mixed-signal Oscilloscope
-
secure checkout
-
30 Day return Policy
Specification
- Analog channel bandwidth: Up to 1 GHz
- Maximum sampling rate: 10 GSa/s
- Maximum storage depth: 1 Gpts (standard configuration)
- Waveform capture rate: ≥800,000 wfms/s (UltraAcq® mode), 2,000,000 wfms/s (Sequence mode)
- Multiple trigger types: Edge, pulse width, slope, video, code pattern, timeout, runt, setup & hold, delay, duration, Nth-edge
- Serial protocol analysis: 11 kinds: RS232/422/485/UART, I²C, SPI, CAN, CAN-FD, LIN, FlexRay, SENT, MIL-STD-1553, ARINC 429, AudioBus (I2S/LJ/RJ/TDM)
- 7-in-1 Instrument: Digital oscilloscope, logic analyzer, spectrum analyzer, function/arbitrary waveform generator, digital voltmeter, frequency meter, protocol analyzer
- Parameter Measurements: 48 kinds, supports histogram, trace, and tendency chart
- Advanced Measurement Functions: Power analysis (optional), jitter & eye diagram (optional), template test, histogram
- Operating System: Windows 10 64-bit with a 15.6-inch high-definition capacitive touchscreen, supports gesture operations such as clicking, sliding, zooming, and dragging
- WebServer: Built-in, accessible via browser with PC/smartphone layouts, enabling cross-platform access
- SCPI Support: Standard command set for programmable instruments
- Peripheral Interfaces: USB Host/Device, LAN, HDMI, AUX In/Out, 10 MHz Ref In/Out
- Waveform Operations: 8-channel waveform operation with built-in frequency spectrum analysis, peak search function, and enhanced resolution up to 3 bits
- Matlab Integration: Supports embedded programming and data presentation
- Waveform Generator: Built-in dual-channel function/arbitrary waveform generator with 60 MHz equivalent performance
- Logic Analyzer: 16-channel with 1.25 GSa/s sampling rate, 125 Mpts storage depth
- For more Details please check data sheet Here
Features
Comparison
Model | MSO7204X | MSO7104X |
Bandwidth | 2GHz | 1GHz |
Channels | 4 Analog + 16 Digital Channels(Optional) | |
Real Time Sample | 10 GSa/s | |
Max. Memory Depth | 1Gpts | |
Waveform Capture Rate | 2.000,000wfms/s | |
Waveform Generatore |
60MHz Dual Channels(optional)
|
Related Document
Data Sheet
MSO3000X Series Digital Oscilloscopes - Data SheetQuickstart Guide
MSO3000X & MSO2000X Series Digital Oscilloscopes - QuickStart GuideUser Manual
MSO2000X & MSO3000X Series Digital Oscilloscopes - User ManualProgramming Manual
MSO3000X & MSO2000X Series Digital Oscilloscopes - Programming GuideSoftware
Device ManagerOption For MSO7104X Mixed-signal Oscilloscope
-
MSO7000X-BND
Excl. VAT €2.199,00Incl. 19% VAT €2.616,81
Upgrade suit (JITTER, PWR, CANFD, FLEX, SENT, AUDIO, AERO)Download -
MSO7000X-AREO
Excl. VAT €929,00Incl. 19% VAT €1.105,51
Aerospace serial bus trigger and analysis (MIL-STD-1553, ARINC 429)Download -
MSO7000X-AUDIO
Excl. VAT €929,00Incl. 19% VAT €1.105,51
Audio serial bus trigger and analysis (I2S, LJ, RJ, TDM)Download -
MSO7000X-SENT
Excl. VAT €929,00Incl. 19% VAT €1.105,51
Automotive sensor trigger and analysis (SENT)Download -
MSO7000X-FLEX
Excl. VAT €929,00Incl. 19% VAT €1.105,51
Automotive serial bus trigger and analysis (FlexRay)Download -
MSO7000X-CANFD
Excl. VAT €929,00Incl. 19% VAT €1.105,51
Automotive serial bus trigger and analysis (CAN FD)Download -
-
MSO7000X-JITTER
Excl. VAT €929,00Incl. 19% VAT €1.105,51
Advanced Jitter analysis and Eye diagramDownload -
-
MSO7000X-AWG
Excl. VAT €649,00Incl. 19% VAT €772,31
Dual channel 60 MHz function/arbitrary waveform generator optionDownload -
MSO7000X-BW-10T20
Excl. VAT €3.399,00Incl. 19% VAT €4.044,81
Bandwidth Upgrade from 1 GHz to 2 GHz for MSO7104XDownload
Accessories for MSO7104X Mixed-signal Oscilloscope
-
UT-V23 High voltage probe
Excl. VAT €24,00Incl. 19% VAT €28,56
High voltage probe:(100:1)Bandwidth: 100MHz
voltage: 2000VppDownload -
UT-P20 Passive High voltage probe
Excl. VAT €54,00Incl. 19% VAT €64,26
Passive probe: (100:1) Bandwidth: 250MHz. voltage: 1500VDownload -
UT-P43 Current probe
Excl. VAT €910,00Incl. 19% VAT €1.082,90
Current probe Range :20A AC/DC, Frequency: DC~25MHz,Conversion ratio:100mV/ADownload -
UT-P42 Current probe:DC~150kHz,200A
Excl. VAT €437,00Incl. 19% VAT €520,03
Current probe,DC-150kHz,0.4A-200ADownload -
UT-P41 Current probe:DC~100kHz,100A
Excl. VAT €567,00Incl. 19% VAT €674,73
Conversion ratio:100mV/A, 10mV/A, Current range: 50A~100A Frequency: DC~100kHz, voltage: 600VrmsDownload -
UT-P40 Current probe:DC~100kHz,60A
Excl. VAT €430,00Incl. 19% VAT €511,70
Conversion ratio:50mV/A, 5mV/A, Current range : 0.4A~60A,Frequency: DC~100kHz voltage: 600VrmsDownload -
UT-P32 High voltage differential probe
Excl. VAT €820,00Incl. 19% VAT €975,80
High voltage differential probe: (10:1/100:1) Bandwidth: 100MHz differential voltage: ±1500VppDownload -
UT-P31 High voltage differential probe
Excl. VAT €666,00Incl. 19% VAT €792,54
High voltage differential probe: (10:1/100:1) Bandwidth: 100MHz differential voltage: ±1500VppDownload -
UT-P30 Differential probe
Excl. VAT €379,00Incl. 19% VAT €451,01
Differential probe:(10:1/100:1) Bandwidth: 100MHz differential voltage: ±800VppDownload -
UT-P21 Passive High voltage probe
Excl. VAT €410,00Incl. 19% VAT €487,90
Passive high voltage probe: (1000:1) Bandwidth: 50MHz voltage: DC 15kVrms/AC 10kV(sine wave )Download -
UT-P07 Passive Probe
Excl. VAT €150,00Incl. 19% VAT €178,50
Probe factor:(10:1) Bandwidth: 500MHz.voltage:600VppDownload -
UT-P06 Passive Probe
Excl. VAT €36,00Incl. 19% VAT €42,84
Probe factor:(10:1) Bandwidth: 300MHz.voltage:600VppDownload
